IPL 95 Insulation Plug PA

ARTICLENUMBER9640075132

Plugs for direct fastenings into rigid insulation and ETICS boards

  • Weather-resistant and robust internally threaded nylon plugs for pre-installations into clean or plastered thermal insulation boards and ETICS boards. Prevents effectively cold-bridging.
  • No pre-drilling needed - Sharp cutting tip penetratesnthrough plaster layer and fiberglass mesh.
  • Can be painted over.
  • IPL 95 sales box includes a M8x25 screw bolt to be used as a setting tool.
  • Suitable screws for IPL 95 are 8 mm,10 mm and M8 bolts.
  • Suitable conditions related to screw material: ZP for dry indoor and temporary outdoor use; HGD/MG and A2 for dry and humid indoor use, outdoor in rural areas only; A4 for indoor, outdoor and industrial use.

Product overview

Packaging

Carton: 20 / Pack: 200

Weight

20.3 g

EAN

6416031751325

Material

plastic

Suitable Conditions

Dry indoor, Humid indoor, rural outdoor, Outdoor

Applications

  • Facade fixings
  • Rainwater pipes
  • Pipe supports
  • Lighting
  • Radiators
  • Signs
  • Letterboxes
  • Motion sensors
  • Distance installations
  • Electrical installations
  • HVAC and plumbing fixings

Base Material

Suitable for

Thermal insulation boards

Technical Data

Length (L)

97 mm

Inner drive

SW13

Head diameter (dk)

32 mm

Suitable screw diameter (mm)

8, 10, M8

Suitable screw length (mm)

40+ TFIX

Electrical number (FI)

1310016

Performance Data

Load type

Embedment depth (hnom)

Load direction

Load value

ETA

EPS, PS 15 / EPS PS 20NRec mmTension0,1 kN
