SDF-S-10H-E

ETA-approved acid-resistant frame plugs for heavy loads, flush-mounted

  • Approved for all common building materials.
  • It is advisable to use SDF-KB for fixing metal structures and SDF-S plugs for fixing wooden structures.
  • Reliable installation in problematic building material due to optimised expansion part.
  • Secure hold due to radial expansion.
  • Cr VI-free coating of the screw.
  • Double safety lock against torsion for secure installation.
  • A4 for indoor, outdoor and industrial use.

Product overview

Material

plastic / stainless steel A4

Suitable Conditions

Dry indoor, Humid indoor, rural outdoor, Outdoor

Applications

  • Facade substructures
  • Squared timbers
  • Angle irons
  • Windows frames
  • Door frames
  • Thick fixtures
  • Cabinets and wardrobes

Base Material

Approved for

Aerated concrete block
Cracked concrete
Non cracked concrete
Perforated clay brick
Perforated sand-lime brick
Solid clay brick
Solid sand-lime brick

Suitable for

Natural stone
Light expanded clay aggregate
Solid light expanded clay aggregate block

Approvals / Certificates

ETA & DOP (ETA-10-0305)
CE Sign (ETA-10-0305)
Fire resistance (ETA-10-0305)
